Features:

• High-performance digital standard for precise control
• Low noise operation with extended service life
• Compact design delivering high torque output
• Suitable for RC cars, boats, and helicopter models

Specifications:

Operating Voltage : 4.8~6.0V DC
Max. Torque : 9kgfcm
No Load Speed : 4.8V0.10sec/60; 6.0V0.12sec/60
Stall Current:4.8V1500mA;6.0V1800mA
Consumption Current* (No Load):4.8V 200mA ;6.0V210mA
Max. Operating Travel Angle:18010(1000~2000s)
Dead Band Width: 1us
Mechanical Limit Angle: 360
Communication Interface: PWM
Motor Type: Core motor
Case Material: ABS
Gear Set Material : Metal gear
Weight: 20.7 g
Size: 29.6 13.2 40mm
